| Technical Specifications | |
|---|---|
| Vendor Name | Professional Manufacturer |
| Form Factor | SFP |
| Max Data Rate | 4.25Gbps |
| Wavelength | 850nm |
| Max Cable Distance | 300m |
| Connector | Duplex LC |
| Media | MMF |
| Transmitter Type | VCSEL |
| Receiver Type | PIN |
| TX Power | -9 ~ 0dBm |
| Receiver Sensitivity | < -15dBm |
| DDM/DOM | Supported |
| Protocols | MSA Compliant |
| Temperature Range | 0 to 70°C / -40 to 85°C |
| Warranty | 5 Years |
| Part Number | Data Rate | Wavelength | Distance | Media | DDM |
|---|---|---|---|---|---|
| LS-MM854G-S1C | 4.25Gbps | 850nm | 150m | Multi-mode | Yes |
| LS-MM852G-S3C | 4.25Gbps | 850nm | 300m | Multi-mode | Yes |
| LS-MM854G-S5C | 4.25Gbps | 850nm | 500m | Multi-mode | Yes |
| LS-SM314G-02C | 4.25Gbps | 1310nm | 2km | Single Mode | Yes |
| LS-SM314G-04C | 4.25Gbps | 1310nm | 4km | Single Mode | Yes |
| LS-SM314G-10C | 4.25Gbps | 1310nm | 10km | Single Mode | Yes |
| LS-SM314G-40C | 4.25Gbps | 1310nm | 40km | Single Mode | Yes |
| LS-SM554G-40C | 4.25Gbps | 1550nm | 40km | Single Mode | Yes |
End-to-end DWDM devices including active modules and optical passive devices like EDFA, Mux & Demux, ROADM, and OTDR.
High-speed optical modules ranging from 10G to 800G, providing high-quality interconnection solutions for modern data centers.
Reliable solutions including Dark Fiber, WDM, and Radio over Fiber for Mid-haul and Back-haul 4G/5G systems.
We are a specialized manufacturer of magnetic telecom and networking components, including RJ45 connectors, LAN transformers, and a full range of SFP modules.
Yes, we provide free samples to test quality. Customers are only responsible for the shipping fees.
Stock items are ready to ship immediately. For mass production orders, the delivery time generally ranges from 15 to 30 days.
We offer a one-year guarantee period and provide 24-hour online technical support to ensure seamless operation.
Yes, we accept both OEM and ODM orders. We can customize products based on your specific technical requirements.
With over 19 years of production experience, we maintain strategic partnerships with global industry leaders and adhere to rigorous international quality standards.
