| Part No. | LS-BL315501-40C |
| Form Factor | SFP |
| Max Data Rate | 155Mbps |
| Wavelength | 1310nm-TX/1550nm-RX |
| Max Cable Distance | 40km |
| Connector | Simplex LC |
| Media | SMF |
| Transmitter Type | FP |
| Receiver Type | PIN |
| TX Power | -8 ~ -1dBm |
| Receiver Sensitivity | < -32dBm |
| EMC Supported | Yes |
| DDM/DOM | Supported |
| Protocols | SFP MSA and SFF-8472 |
| Temperature Range | 0 to 70°C / -40 to 85°C |
| Warranty | 5 Years |
| Sample | Available |
We draw on over 10 years of experience in chips and modules to integrate fast speeds, small size, power savings, and high performance in every module. We provide a full series of optical modules for fixed access, wireless access, carrier Ethernet, wavelength division multiplexing (WDM), and data communication networks.
| Part Number | Data Rate | Wavelength | Distance | Components | DDM |
|---|---|---|---|---|---|
| LS-BL315501-10C | 155Mbps | 1310TX/1550RX | 10km | FP/PIN | Yes |
| LS-BL553101-10C | 155Mbps | 1550TX/1310RX | 10km | FP/PIN | Yes |
| LS-BL315501-15C | 155Mbps | 1310TX/1550RX | 15km | FP/PIN | Yes |
| LS-BL553101-15C | 155Mbps | 1550TX/1310RX | 15km | FP/PIN | Yes |
| LS-BL315501-20C | 155Mbps | 1310TX/1550RX | 20km | FP/PIN | Yes |
| LS-BL315501-40C | 155Mbps | 1310TX/1550RX | 40km | FP/PIN | Yes |
| LS-BL315501-80C | 155Mbps | 1310TX/1550RX | 80km | FP/PIN | Yes |
| LS-BL495501-80C | 155Mbps | 1490TX/1550RX | 80km | DFB/PIN | Yes |
We are a specialized manufacturer of magnetic telecom and network components, certified by ISO9001:2000, ROSH, REACH, CE and UL. Established in 1997, we currently employ approximately 2000 staff members. With a production capacity of 3000K per month, we ensure short delivery times for all orders.
Our expertise includes a complete series of optical modules for fixed access, wireless access, carrier Ethernet, WDM, and high-speed data interconnection for cloud computing and ultra-broadband networks. Using the latest optoelectronic technologies, we design and manufacture high-performance products for the global market.
