| Item | 40G Optical Modules |
| Replaceable Part | Cisco, HW, Arista, Juniper, Brocade, Intel, etc |
| Part Status | Active |
| Form Factor | QSFP+ |
| Max Data Rate | 41.25Gbps (4x 10.3125Gbps) |
| Wavelength | 850nm |
| Max Cable Distance | 150m@OM4 / 100m@OM3 |
| Media | MMF |
| Connector | MTP/MPO-12 Male |
| Optical Component | VCSEL/PIN |
| TX Power | -7.1~1.9dBm |
| Receiver Sensitivity | < -10.3dBm |
| Powerbudget | 3.5dB |
| Receiver Overload | 2.4dBm |
| Power Consumption | ≤1.5W |
| Extinction Ratio | >3dB |
| DDM | Supported |
| Commercial Temperature Range | 0 to 70°C (32 to 158°F) |
| Protocols | IEEE 802.3ba, QSFP+ MSA, SFF-8436, SFF-8636 |
| Warranty | 5 Years |
| Sample | Available |
Drawing on over 10 years of experience in chips and modules, we integrate fast speeds, small size, power savings, and high performance in every module. Our full series of optical modules is designed for fixed access, wireless access, carrier Ethernet, wavelength division multiplexing (WDM), and data communication networks.
Optical Transport Networks: End-to-end DWDM device support from active modules to passive devices, including amplifiers, Mux/Demux, and ROADM.
Cloud and Enterprise: High-speed optical modules (10G to 800G) providing high-quality interconnection for modern data centers.
Wireless: High reliability products for 4G/5G systems including Dark Fiber, WDM, and Radio over Fiber solutions.
FTTx: Total optical fiber access solutions covering all-optical or combined access requirements for global networks.
Subsystems: Optical cable O&M solutions integrating line protection (OLP) and monitoring systems (OLM).
We are a specialized manufacturer of magnetic telecom and networking components, certified by ISO9001:2000, RoHS, REACH, CE, and UL. Our facilities utilize advanced manufacturing and test equipment to ensure peak performance.
Established in 1997, our production capacity reaches 3000K per month, ensuring short delivery times. We provide a full range of high-speed optical interconnection solutions for cloud computing and ultra-broadband networks worldwide.
