Fiber Optic Equipment Multi Mode Duplex LC Optical Transceiver Module QSFP-40G-SR-BD
We draw on over 10 years of experience in chips and modules to integrate fast speeds, small size, power savings, and high performance in every module. Our solution provides a full series of optical modules for fixed access, wireless access, carrier Ethernet, wavelength division multiplexing (WDM), and data communication networks.
| Item | QSFP-40G-SR-BD |
| Part Status | Active |
| Form Factor | QSFP+ |
| Max Data Rate | 40Gbps |
| Wavelength | 832nm - 918nm |
| Max Cable Distance | 300m@OM3 |
| Media | MMF |
| Connector | Duplex LC |
| Optical Component | VCSEL/PIN |
| TX Power | -4~5dBm |
| Receiver Sensitivity | <-6dBm |
| Power Consumption | ≤3.5W |
| DDM/DOM | Supported |
| Temperature Range | 0 to 70°C (32 to 158°F) |
| Protocols | 40G Ethernet, IEEE802.3ba-2010, MSA Compliant |
| Warranty | 5 Years |
| Sample | Available |
We provide end-to-end DWDM device with almost all optical devices - from active modules to optical passive devices, including optical amplifier(EDFA & RFA), Mux & Demux, OPM, ROADM, MCS, OLP and OTDR etc.
To meet the demand of mass data transmission in data centers, we have developed a series of high-speed optical modules with product rates ranging from 10G to 800G, providing high-quality solutions.
The solution includes Dark Fiber, WDM, Radio over Fiber, High Speed, Mid-haul and Back-haul which could meet all the needs of various scenarios in 4G/5G systems.
Providing FTTx optical fiber access total solutions covered from all-optical or optical copper combined access solutions and products for global communication constructors.
Our company is a specialized manufacturer of magnetic telecom and networking components, certificated by ISO9001:2000, ROSH, REACH, CE and UL. We own advanced manufacturing facilities and test equipments imported from abroad. Established in 1997, we have approximately 2,000 staff members. With an abundant productive capacity of 3000K per month, we are able to deliver products within a short time. We provide a full series of optical modules for fixed access, wireless access, carrier Ethernet, WDM, and data communication networks.
