Send Inquiry

Product Description

1
Product Description
Product Characteristics
Characteristics:
  • RJ45 Connector with integrated transformer / common mode choke
  • Power over Ethernet up to 50 Watt and speeds up to 10 Gbit/s
  • Available in SMT, THT and THT with USB
  • Compliant with standards: IEEE 802.3u, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at and upcoming IEE 802.3bt
  • HPLE products: Improved Common Mode Rejection due to additional NiZn cores
2
Specification
Item Value
Model NumberIntegrated Connector Modules
Part StatusActive
Connector TypeRJ45
Applications-LanEthernet(PoE/Non_PoE)
Speed10/100/1000/2.5G/5G/10G Base-T, AutoMDIX
Mounting TypeThrough Hole
Orientation90° Angle (Right)
TerminationSolder
Contact Finish Thickness6.00µin (0.152µm)
LED ColorYellow/Green, Green/Yellow, Green&Yellow/Green&Yellow
Number of Cores per Jack4/6/8/12
ShieldingShielded, Emi Finger
Number of Ports1x2 1x4 1x6 1x8 Port
FeaturesBoard Guide
Tab DirectionDown/Up
Contact FinishGold
Configuration RX/TXT,C
Turns Ratio RX/TX1CT:1CT
Operating Temperature0°C ~ 70°C / -40°C ~ +85°C
3
Packing & Delivery
Package Details:
Tray packing, Carton size: 37*30*30cm, G.W./carton: 9kg, Qty/carton: 600pcs, SPQ: 30pcs, N.W/pcs: 0.015kg.
Packing Details
4
Production Showcase
?
Frequently Asked Questions
How do you ensure the quality of your RJ45 connectors?
We always provide a pre-production sample before mass production and conduct a final inspection before shipment to ensure strict quality standards.
What speeds do these integrated connector modules support?
Our connectors support a wide range of speeds including 10/100/1000 Base-T, as well as high-speed 2.5G, 5G, and 10G Base-T applications.
Are these products compliant with Power over Ethernet (PoE) standards?
Yes, they support PoE up to 50 Watt and are compliant with IEEE 802.3af, IEEE 802.3at, and the upcoming IEEE 802.3bt standards.
What is the typical lead time and packing method?
Products are typically packed in trays within standard cartons (37*30*30cm). We offer various delivery terms including FOB, CFR, CIF, EXW, and DDP to suit your needs.
What types of magnetic components can I purchase from you?
We specialize in RJ45 Magnetic connectors, LAN transformers, RJ11 connectors, and SFP modules with various port configurations.
Do the connectors operate in extreme temperature environments?
Yes, we offer components with operating temperature ranges from 0°C ~ 70°C for standard use and -40°C ~ +85°C for industrial applications.
